For Sale Blue Torch Fab Buggy on Dana 80s

corey_moon

Member
Joined
Jun 9, 2017
Messages
16
Blue Torch Fab Evil X Chassis for sale. Chassis was built in 2007 and then rebuilt to the current version around 2017. I've owned this buggy for 2.5 years and it's been awesome! I am not online very much at all so please call or text to discuss the buggy.

Price: $32,000
Location: Magnolia, Tx. 77354. Close to The Woodlands, Tx.

832 972-6666

Engine:
6.0 truck block bored .030" over
LS3 heads and intake
95mm Holley Throttle body
Transmission:
TH350 with 2500 stall. Installed in new K case June 2019
T-Case
Atlas 3.8 with 1410 flange style yokes
Front Axle:
Custom Dana 80 with Rockwell knuckles and 4" OD tube
Ouverson 47 spline 2" chromo shafts
4.88 gears on custom Ouverson spool
Rear mounted 2.5" PSC double ended ram
1.25" thick aluminum high steer arms
Wilwood Brakes on Ouverson Super 8 Hubs
3/8" plate diff cover
1410 yoke
Rear Axle:
Dana 80 35 spline
4.88 gear and spool
4 piston wilwood calipers on OEM disc brakes
1410 yoke
Wheels/Tires:
43" SX stickies
16.5” TWF H1 Double Beadlocks
Suspension:
4 link front and rear
16" all black ORIs, just rebuilt with all new o-rings and schrader valves
7075 Aluminum lower links
Misc.
113" wheelbase
Warn 8274-50 winch with synthetic rope


Attachments

  • Capture.JPG
    544.4 KB · Views: 1,360
  • 163305975_263788598733301_2404880663055609838_n.jpg
    69.1 KB · Views: 1,288
  • IMG_3092 (1).jpg
    IMG_3092 (1).jpg
    64.8 KB · Views: 1,098
  • buggy back.jpg
    buggy back.jpg
    72.1 KB · Views: 1,001
  • unnamed.jpg
    63.2 KB · Views: 1,312
Last edited:

corey_moon

Member
Joined
Jun 9, 2017
Messages
16
Whoops, my apologies; I’ll update when I gets to a computer. Price is 32,000 and it’s located in Magnolia,Tx.
