For Sale SXOR Rear Engine Rock Crawler

DocBrad

New Member
Joined
Oct 3, 2015
Messages
1
SXOR Rear Engine Buggy Turn key buggy that needs nothing, it is ready to tackle anything or any 9-10 trail. Only reason for selling this is because I bought a single seat buggy when I was in Utah this year at Trail Hero in March 2021. You are more than welcome to come and drive or have it inspected. I will help with shipping on my end if a transport company is needed. This buggy has the best of everything with no exceptions taken when replaced or built.

Engine: Chevy 383 cc - 550HP ported and polished heads with matching intake. Remote filter and electric oil cooler with a oil accumulator. Holly sniper fuel injection system Custom headers and exhaust

Transmission: Custom built 2 speed power glide with reverse valve body with a 2500 stall in a Reed bullet proof case. Transmission cooler Cheetah shifter

T-Case Atlas 5:1 with 1410 flange style yokes adjustable cable shifters

Front Axle: Dana 60 shortened Spider Trax 4130 with Spider Trax Ultimate 300M series joints, steering hub angles of 50 degrees. 5.13 gears on Ox air actuated locker with drive away locks if needed. Yukon Super Joints 2.5" PSC double ended ram 1.25" thick aluminum high steer arms Spider Trax 14 inch Rotor with Wilwood Calipers High Angle Driveline front drive shaft with 1410 yokes.

Rear Axle: Shortened Dana 60 flipped over to make high angle pinion 35 spline Branik chromo shafts 5.13 gear on Ox air actuated locker Spider Trax 14 inch Rotor with Wildwood Calipers High Angle Driveline rear drive shaft with 1410 yokes Adjustable anti rock rear sway bar

Wheels/Tires: 43" SX stickies lots of tread on 17" Raceline

Suspension: Triangulated 4 link using 1.25” Rod Ends and 7075 Branik links 16" ORIs, rebuilt with all new o-rings and schrader valves

Misc. Right and Left rear cutting brakes 112" wheelbase 83” outside/outside tire Overall weight 3200 Belly Pan Clearance 21.5” Warn RC9 winch with 50’ synthetic rope PSC steering cooler with fan Oil cooler with fan 12 gallon fuel cell Wired for Rugged Radio system, Spare rear/front axle shafts and drive shaft

Price: $39,000 Location: West Bloomfield Mi, Not far from Detroit
