Supercharged rear steer buggy
--------------------------------------------------------------------------------
This buggy was finished in 2008. I am putting it up for a customer of mine who is from Florida. The buggy is currently at my shop in NORTH CAROLINA.
Full build up at MandMfab.com
$19,800.00
Genereal info and To arrange to see buggy....336-909-2076 PJ
Pricing and Engine Information.....386-366-2395 Fred(owner)
Specs.
Supercharged Toyota hybrid engine
22r block bored .30 over with LC pistons/rings
20r head with port and polish, viton seals, ss valves, LC head gasket
Balanced crank
Schneider racing cam
LC adjustable cam gear
Gotpropane propane kit
LC/Camden supercharger, hi boost
LC long tube header
1 wire gm alternator
200+ hp
chassis is 1.5" 120 wall DOM tubing, Powdercoated black, plastic side panels, aluminum accents for firewall and center console. Hood is narrowed and pie cut Fj40. 51" wide chassis, Very Roomy and comfortable, Master craft Seats
toyota 5 spd tranny, dual cases Mini truck to Fj40 case.(so both driveshafts are on the passenger side.
Wheels are 17" Walker Evans aluminum Wrapped with 70% tread STICKY 40" Creepy crawlers.
Shocks are 14" travel Fox 2.0's all around.
fox air bumps in the front
Poly performance quad wrap limiting straps front and rear
suspension... Front and rear double triangulated 4 link with adjustable jhonny joints all around. Aluminum lower links
Tmaxx winch
Head lights are hella 500's, has Rock lights and Led tail lights.
Propane injection with all new parts or rebuilt parts.
comes with 1 Fiberglass tank and 2 Aluminum tanks.
Spare parts. 1 complete fj40 tcase and 2 for spares, random toyota parts if you buy with toyota axles.
Front and Rear steering Axle specs
Bobby long 30 spline inner and outer front and rear.
trail -gear Drive Flanges front and rear
high steer over the thirds
529 gears and spooled front and rear.
--------------------------------------------------------------------------------
This buggy was finished in 2008. I am putting it up for a customer of mine who is from Florida. The buggy is currently at my shop in NORTH CAROLINA.
Full build up at MandMfab.com
$19,800.00
Genereal info and To arrange to see buggy....336-909-2076 PJ
Pricing and Engine Information.....386-366-2395 Fred(owner)
Specs.
Supercharged Toyota hybrid engine
22r block bored .30 over with LC pistons/rings
20r head with port and polish, viton seals, ss valves, LC head gasket
Balanced crank
Schneider racing cam
LC adjustable cam gear
Gotpropane propane kit
LC/Camden supercharger, hi boost
LC long tube header
1 wire gm alternator
200+ hp
chassis is 1.5" 120 wall DOM tubing, Powdercoated black, plastic side panels, aluminum accents for firewall and center console. Hood is narrowed and pie cut Fj40. 51" wide chassis, Very Roomy and comfortable, Master craft Seats
toyota 5 spd tranny, dual cases Mini truck to Fj40 case.(so both driveshafts are on the passenger side.
Wheels are 17" Walker Evans aluminum Wrapped with 70% tread STICKY 40" Creepy crawlers.
Shocks are 14" travel Fox 2.0's all around.
fox air bumps in the front
Poly performance quad wrap limiting straps front and rear
suspension... Front and rear double triangulated 4 link with adjustable jhonny joints all around. Aluminum lower links
Tmaxx winch
Head lights are hella 500's, has Rock lights and Led tail lights.
Propane injection with all new parts or rebuilt parts.
comes with 1 Fiberglass tank and 2 Aluminum tanks.
Spare parts. 1 complete fj40 tcase and 2 for spares, random toyota parts if you buy with toyota axles.
Front and Rear steering Axle specs
Bobby long 30 spline inner and outer front and rear.
trail -gear Drive Flanges front and rear
high steer over the thirds
529 gears and spooled front and rear.
