blacksheep10
XBJRA champ/ 555 and team Nasty codriver
In the tech section, the teal TJ on tons with atlas and MattO's old airs on 44 tsl's is for sale
16K
Full pirate thread and write up with specs and pics here
http://www.pirate4x4.com/forum/showthread.php?p=11699840#post11699840
A copy and paste of the specs:
For sale is the Vertical Limits built 1 ton "lowrider" TJ.
When it was built it was done with uptravel in mind, not necessarily being low. That said, it does sit low for 44's.
Asking $16,500.
Specs:
112" wheelbase
1997 TJ, 4.0 liter with later model intake
-Stock auto tranny, 32RH
-Atlas 4.3 Pass drop with 1410 yokes and 32 spline outs
-44 16.5" TSL's with 90% tread. Cross cut pattern on them. Recentered H1 wheels with stamped centers, 3.5" backspace. Rock rings by Vertical Limits.
-1410 shafts everywhere but the axle yokes, 1350 there. 1410 2 pc front shaft
-Front Chevy 60, stock inners, 806's and chromo outers with R&R drive flanges. 4.56 gears, welded ( have a spare carrier for it) DE ram 8" stoke, Parts Mike springless arms, fresh all the way through. Billet 1350 yoke and BTF cover
-14 rear, BTF truss and cover, disc brakes, 4.56 with detroit, stock yoke, and pinion guard
-Double triangulated front and rear suspension with 2.0 Fox air shox, 2.5" air bumps on the front. Joints are all 1.25" shank/ weld on Johnny, links are all 3/8" wall DOM
-Aluminum radiator with electric fans.
-Full hydro with POS orbital and filter resi combo, Howe tc pump, and Setrab cooler from POS
-Frame backhalved and dove tailed to fit whatever suspension is desired, 1.75" DOM rails and cage.
-Cage is frame tied 100%, seats and shifter on cage, and body sandwiched to cage. All 1.75"OD .120" wall DOM tubing
-Winch plate sunk between rails in the front with Xline fairlead
-Corbeau suspension seats and 5 point harnesses.
-Aluminum fuel cell with factory sender ring tig welded in. Plenty of storage behind it.
-Ram 3500 master cylinder, it stops on a dime.
It drives down the highway at speed without batting an eye, and has plenty of power and the steering is natural feeling
It is a ready to ride dependable rig, it is just KOH buggy time
Build thread here:
http://www.pirate4x4.com/forum/showthread.php?t=787917
Location: Paola, KS 66071
Contact Brandon to deal
913.375.7429
Technical questions or a quick hand job call me, Kelly (that had to be a nolen edit lol)
913.731.3040
16K
Full pirate thread and write up with specs and pics here
http://www.pirate4x4.com/forum/showthread.php?p=11699840#post11699840
A copy and paste of the specs:
For sale is the Vertical Limits built 1 ton "lowrider" TJ.
When it was built it was done with uptravel in mind, not necessarily being low. That said, it does sit low for 44's.
Asking $16,500.
Specs:
112" wheelbase
1997 TJ, 4.0 liter with later model intake
-Stock auto tranny, 32RH
-Atlas 4.3 Pass drop with 1410 yokes and 32 spline outs
-44 16.5" TSL's with 90% tread. Cross cut pattern on them. Recentered H1 wheels with stamped centers, 3.5" backspace. Rock rings by Vertical Limits.
-1410 shafts everywhere but the axle yokes, 1350 there. 1410 2 pc front shaft
-Front Chevy 60, stock inners, 806's and chromo outers with R&R drive flanges. 4.56 gears, welded ( have a spare carrier for it) DE ram 8" stoke, Parts Mike springless arms, fresh all the way through. Billet 1350 yoke and BTF cover
-14 rear, BTF truss and cover, disc brakes, 4.56 with detroit, stock yoke, and pinion guard
-Double triangulated front and rear suspension with 2.0 Fox air shox, 2.5" air bumps on the front. Joints are all 1.25" shank/ weld on Johnny, links are all 3/8" wall DOM
-Aluminum radiator with electric fans.
-Full hydro with POS orbital and filter resi combo, Howe tc pump, and Setrab cooler from POS
-Frame backhalved and dove tailed to fit whatever suspension is desired, 1.75" DOM rails and cage.
-Cage is frame tied 100%, seats and shifter on cage, and body sandwiched to cage. All 1.75"OD .120" wall DOM tubing
-Winch plate sunk between rails in the front with Xline fairlead
-Corbeau suspension seats and 5 point harnesses.
-Aluminum fuel cell with factory sender ring tig welded in. Plenty of storage behind it.
-Ram 3500 master cylinder, it stops on a dime.
It drives down the highway at speed without batting an eye, and has plenty of power and the steering is natural feeling
It is a ready to ride dependable rig, it is just KOH buggy time
Build thread here:
http://www.pirate4x4.com/forum/showthread.php?t=787917
Location: Paola, KS 66071
Contact Brandon to deal
913.375.7429
Technical questions or a quick hand job call me, Kelly (that had to be a nolen edit lol)
913.731.3040
ITS IN ALABAMA NOW
